IDEC SmartRelay FL1D Series User Manual

Technical data
299
IDEC SmartRelay Manual
Analog inputs
Number 2 (I7 = AI1, I8 =AI2)
Range 0 ... 10 V DC
input impedance
78 k
Ω
Resolution 10 bit, normalized to
0 ... 1000
Cycle time for analog value
generation
300 ms
max. input voltage 28.8 V DC
Line length (shielded and twist-
ed)
10 m
Error limit ±1.5 % of full scale
Digital outputs
Number 4 4
Output type Transistor,
current–sourcing
(4)
Transistor,
current–sourcing
(4)
Electrical isolation No No
In groups of
Control of a digital input Yes Yes
Output voltage Supply voltage Supply voltage
Output current max. 0.3 A max. 0.3 A
Continuous current I
th
Incandescent lamp load
(25000 switching cycles) at
Fluorescent tubes with ballast
(25000 switching cycles)
Fluorescent tubes,
conventionally compensated
(25000 switching cycles)
Fluorescent tubes, uncompen-
sated (25000 switching cycles)
Short circuit–proof and over-
load–proof
Yes Yes
Short–circuit current limitation Approx. 1 A Approx. 1 A
FL1D-H12SND FL1B-M08B1S2
