Programming IDEC SmartRelay
75
IDEC SmartRelay Manual
Note
IDEC SmartRelay has now saved your circuit program to nonvola-
tile memory. The circuit program remains in the IDEC SmartRelay
memory until you explicitly delete it.
You can save the actual values of special functions in the case of a
power outage assuming that these functions support the “Reten-
tive” parameter and that the necessary program memory is avail-
able. The Retentive parameter is deactivated in the basic status
(i.e. when inserting the function). To use it, you must enable this op-
tion.
3.6.4 Assigning a circuit program name
You can assign your circuit program a name that consists of
up to 16 uppercase/lowercase letters, numbers and special
characters.
In the programming menu:
1. To move the “>” cursor to 'Edit..': Press ▼ or ▲
2. To accept 'Edit': Press OK
3. Move the “>” cursor to 'Edit Name': Press ▼ or ▲
4. To accept 'Edit Name': Press OK
Press ▲ and ▼ to list the alphabet from A (a) to Z (z), num-
bers and special characters, either in ascending or descend-
ing order. You can select any letter, number or character.
To enter a space character, simply movie the cursor with
▲
to the next position. This character is the first one in the list.
Examples:
Press ▼ once to select an “ A ”
▲ four times to select “ { ”, etc.
The following character set is available:
ABCDEFGHI J KLMNO
PQRSTUVWXYZabc de
f ghi j kl mnopqr st u
vwxyz0123456789!
"#$%&'()*+,-./:;
<=>?@[ \ ] ^ _‘ { | } ~
