IDEC SmartRelay FL1D Series User Manual

Technical data
297
IDEC SmartRelay Manual
Fluorescent tubes, convention-
ally compensated
(25000 switching cycles)
1 x 58 W
(at 230/240 V AC)
1 x 58 W
(at 230/240 V AC)
Fluorescent tubes, uncompen-
sated (25000 switching cycles)
10 x 58 W
(at 230/240 V AC)
10 x 58 W
(at 230/240 V AC)
Short circuit-proof cos 1 Power protection
B16
600A
Power protection
B16
600A
Short-circuit proof cos 0.5 to
0.7
Power protection
B16
900A
Power protection
B16
900A
Derating none; across the en-
tire temperature
range
none; across the en-
tire temperature
range
Parallel output circuits
for power increase
Not permitted Not permitted
Protection of output relay
(if desired)
max. 16 A,
characteristic B16
max. 16 A,
characteristic B16
Minimum Switching Load 10 mA, 12 V DC 10 mA, 12 V DC
Initial Contact Resistance 100 m
Ωmaximum
(at 1A, 24V DC)
100 mΩ maximum
(at 1A, 24V DC)
Mechanical Life 10,000,000
operations minimum
(no load, 10 Hz)
10,000,000
operations minimum
(no load, 10 Hz)
Electrical Life 100,000 operations
minimum (rated re-
sistive load, 1800
operations / hour)
100,000 operations
minimum (rated re-
sistive load, 1800
operations / hour)
Switching rate
Mechanical 10 Hz 10 Hz
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
FL1D-H12RCC
FL1D-B12RCC
FL1B-M08C2R2
Note: When connecting a fluorescent lamp to the output, take the inrush current into
consideration. When the inrush current exceeds the rated value, connect an ap-
propirate relay between the output and the fluorescent lamp.
