Technical data
IDEC SmartRelay Manual 294
Free fall (packaged) IEC 60068-2-32 1 m
Electromagnetic compatibility (EMC)
Noise emission EN 55011/A
EN 55022/B
EN 50081-1
(domestic area)
Limit class B group 1
Electrostatic discharge IEC 61000-4-2
Severity 3
8 kV air discharge
6 kV contact discharge
Electromagnetic fields IEC 61000-4-3 Field strength 10 V/m
HF currents on cables
and cable shielding
IEC 61000-4-6 10 V
Burst pulses IEC 61000-4-4 Severity 3 2 kV (supply)
1 kV (signal lines)
High-energy surge
pulse (applies only to
FL1D-H12RCC/FL1D-
B12RCC)
IEC 61000-4-5 Severity 3 1 kV (power lines)
symmetrical
2 kV (power lines)
asymmetrical
Safety to IEC / VDE
Clearance and
creepage distance
rating
IEC 60664,
IEC 61131-2,
EN 50178
cULus to UL 508,
CSA C22.2 No. 142
With FL1D-B12RCC/
FL1D-H12RCC, also
VDE 0631
Fulfilled
Insulation strength IEC 61131-2 Fulfilled
Cycle time
Cycle time per function < 0.1 ms
Startup
Startup time at power-
up
typ. 8 s
Criterion Tested in
accordance with
Values
Note: Use a surge absorber, noise cut transformer, or noise filter to protect DC pow-
er type modules (FL1D-H12RCE/B12RCE, FL1D-H12SND, FL1D-H12RCA/
B12RCA) against surge.
