IDEC SmartRelay functions
227
IDEC SmartRelay Manual
Sampling time
The sampling time is fixed at 500 ms.
Parameter sets
For more information and application examples with
application-related parameter sets for KC, TI and Dir refer to
the online help for WindLGC.
Preset of the Par parameter
View in programming mode (example):
B3 1+/
SP B020
B3 2+/
KC 10.00
TI 01:00
Dir=+
B3 4+/
A 02.50
B 00300
p0
B3 2+/
KC
TI
=+
B3 3+/
Mq B021
Min 05000
Max 05000
=+
=
=
=
–
=
–
=
=
Press
▲
▲
Press
▲
▲
Press
▲
▲
