Configuring IDEC SmartRelay
231
IDEC SmartRelay Manual
Description of the four menu items of the parameter assignment
menu
•Stop
You select this command to stop your circuit program and
thus change to the main menu of programming mode. To do
so:
1. To move the ‘>’ cursor to ‘Stop’: Press ▲ or ▼
2. To confirm ‘Stop’: Press OK
3. To move the ‘>’ cursor to ‘Yes’: Press ▲ or ▼
4. To confirm ‘Yes’: Press OK
IDEC SmartRelay shows the main menu of the programming
mode:
>Program..
Card..
Setup..
Start
• Set Param
For information on the various parameters, refer to the
Chapters
5.1.1 to 5.1.3.
•Set..
For information on the various settings, refer to Chapter 5.2.
• Prg Name
This menu command only allows you to read the name of
your circuit program. It is not possible to modify this name in
parameter assignment mode. (see Chapter
3.6.4.)
Stop Prg
>No
Yes
