Configuring IDEC SmartRelay
235
IDEC SmartRelay Manual
Current timer value
View of a timer cam in parameter assignment mode:
B1 1
Off=10:00
D=M-W-F--
On = 09:00
You can change the on/off times and the day.
Current value of a counter
View of a counter parameter in parameter assignment mode:
B3
On =001234
Off=000000
Cnt=000120
B3
On =123456
Off B021
Cnt=000120
or
Current
count value
You can change the On/Off threshold. This does not apply if
the on or off threshold represents the result of another func
-
tion (in the example, this is B21, see Chapter 4.4.13).
Current value of an hour counter
View of an hour counter parameter in parameter assignment
mode:
B16
MI = 0100h
MN = 0017h
OT =00083h
Time interval
Time-to-go
Total operating hours
You can edit the configured time interval MI.
