IDEC SmartRelay memory cartridge (card)
251
IDEC SmartRelay Manual
Note
Before you switch the IDEC SmartRelay to RUN, you must ensure
that the system you are controlling with IDEC SmartRelay does not
represent a source of hazard.
1. Move the ‘>’ cursor to ‘Start’:Press ▲ or ▼
2. Press OK.
Copying by means of the “Card” menu
For information on the replacement of a memory cartridge
(card), also note Chapter 6.2.
To copy a program from the memory cartridge (card) to IDEC
SmartRelay:
1. Insert the memory cartridge (card)
2. Switch IDEC SmartRelay to programming mode (ESC /
>Stop).
3. Move the ‘>’ cursor to ‘Card’: Press ▲ or ▼
4. Press OK. The transfer menu opens.
5. Move the ‘>’ cursor to ‘Card → IDEC SmartRelay’:
Press ▲ or ▼
6. Press OK.
IDEC SmartRelay copies the circuit program from the
memory cartridge (card) to IDEC SmartRelay. When IDEC
SmartRelay has finished copying, it automatically returns to
the main menu.
>Program..
Card..
Setup..
Start
= IDEC
SmartRelay
Card
>Card
CopyProtect
