IDEC SmartRelay FL1D Series User Manual

Technical data
IDEC SmartRelay Manual 302
Delay time at
•0 to 1
•1 to 0
typ. 1.5 ms
typ. 15 ms
typ. 1.5 ms
typ. 15 ms
Line length (unshielded) 100 m 100 m
Analog inputs
Number
Range
max. Input voltage
Digital outputs
Number 4 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
Dielectric Strength
(between power/input
terminals and output terminals)
2,500 V AC, 1minute
500 V DC, 1 minute
2,500 V AC, 1minute
500 V DC, 1 minute
In groups of 1 1
Control of a digital input Yes Yes
Output voltage
Output current
Continuous current I
th
max. 10 A per relay max. 5 A per relay
Surge current max.30A max.30A
Incandescent lamp load
(25000 switching cycles) at
1000 W 1000 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W 10 x 58 W
Fluorescent tubes, convention-
ally compensated
(25000 switching cycles)
1 x 58 W 1 x 58 W
Fluorescent tubes, uncompen-
sated (25000 switching cycles)
10 x 58 W 10 x 58 W
Short circuit–proof and
overload–proof
FL1D-H12RCA
FL1D-B12RCA
FL1B-M08D2R2
