IDEC SmartRelay FL1D Series User Manual

IDEC SmartRelay installation and wiring
43
IDEC SmartRelay Manual
Output Internal Circuit
FL1D-H12RCA / FL1D-B12RCA / FL1D-H12RCC / FL1D-B12RCC /
FL1D-H12RCE/ FL1D-B12RCE / FL1B-M08B2R2 / FL1B-M08C2R2/
FL1B-M08D2R2
Relay Output
FL1D-H12SND / FL1B-M08B1S2
Transister Output (Source)
FL1D-K2B2
Analog Output (0-10V)
27kΩ
47kΩ
+24V
2
1
Q1~Q4
Internal
Circuit
Internal Circuit
+24V
10kΩ10nF 10nF
M
Q1~Q4
Internal
Circuit
Internal Circuit
10Ω
100nF
+24V Internal Circuit
4.7kΩ
+
-
Internal
Circuit
(
V1+, V2+
)
(
M1, M2
)
