Programming IDEC SmartRelay
IDEC SmartRelay Manual 88
Setting the time
Set the time T = 12:00 minutes:
1. Move the cursor to the first digit: Press or
2. Select the digit '1': Press ▲ or ▼
3. Shift the cursor to the second digit: Press or
4. Select digit '2': Press ▲ or ▼
5. Move the cursor to the unit: Press or
6. Select the timebase 'm' (for minutes): Press ▲ or ▼
Showing/hiding parameters - the parameter protection mode
If you want to show/hide the parameter and allow/prevent its
modification in parameter assignment mode:
1. Move the cursor to the protection mode: Press or
2. Select the protection mode: Press ▲ or ▼
The display should now show:
T=12:00m
B2 +R
T=12:00m
B2
R
or
Protection mode +:
The value of the time T can be
modified in parameter assign-
ment mode.
Protection mode --:
The value of the time T is hid-
den in parameter assignment
mode
3. Confirm your entries with: OK
Enabling/disabling retentivity
To decide whether you want to retain your current data after
a power failure or not:
1. Move the cursor to the retentivity setting:Press or
2. Select the retentivity setting: Press ▲ or ▼
▲
▲
▲
▲
▲
▲
▲
▲
▲
▲
