103
6. Specification
Model
SMART-81S
SMART-81D
Printing
Print Type
Dye-Sublimation & Retransfer
Print Area
Edge to Edge
Resolution
300dpi
Dual Side Printing
Option
Yes
Card
Card Feeding
Automatic
Card Size
ISO CR80
Card Thickness
0.8mm ~ 1.6mm
Card Type
PVC, PET, Composite PVC
Printing Speed
Monochrome
20sec./card (180 cards/hour)
YMCK
Max. 30 sec./card (120 cards/hour)
YMCKK
_
Max. 50 sec./card (72 cards/hour)
Capacity
Input Hopper
200 Cards
Output Hopper
100 Cards
Error Card Bin
25 Cards
System
Memory
64MB RAM
Display
LCD
Control Panel
4 Buttons
Supported
Platforms
MS Windows 7/ 8/ 10/ 11, Mac OS, Linux
Communication
USB, Ethernet
Power Supply
100-240V~ 50/60Hz 2.5A
Temp. / Humidity
15~35℃ / 35~70%
Dimensions
Millimeter (WxLxH)
165 x 390 x 210
165 x 498 x 210
Inch (WxLxH)
6.5 x 15.4 x 8.3
6.5 x 19.6 x 8.3
Weight
Kg / Lbs
4.5 / 10
5.2 / 11.5
Encoding Options
Magnetic
ISO 7811 (Track I, II, III Read/ Write, HiCo/ LoCo), JIS II
Contact
ISO 7816 (ID-1)
Contactless
MIFARE, ISO 14443 (Type A/ B), ISO 15693, DESFIRE, iCLASS
Certifications
CB, CE, FCC, KC, CCC
Specifications and availability may change without notice
.
