IDS X-Series Installer Manual 700-398-02H Issued July 2013
21
How to program using the string method:
To program 8 zones at a time, fill in a row with the corresponding zone types (2 digits per type, found
in Table 5) and enter these values as one long 16-digit string for location 1. This method can be used for the
remaining 56 zones by noting that location 2 references zones 9 to 16, location 3 references zones 17 to 24,
etc.
I.e. To program the defaulted zone types (Table 6) for the first 16 zones use the following:
[INSTALLER CODE] [*]
[1] [*] reference zones 1 - 8
[0102040404040404] [*]
[2] [*] reference zones 9 - 16
[0000000000000000] [*]
How to program using the sub-location method:
To program zones using the sub-location method, program 1 (as indicated by
“[ ]” sub-location (followed by the [*] key) and then enter the zone type (followed by the [*] key). Then
press the [*] key again to advance to the next sub-location. For sub-locations, the zone type does not have to
be 2 digits, i.e. enter 1 or 01.
To repeat for further zones, enter the second zone number (followed by the [*] key) and then the zone type
(followed by the [*] key). This can be repeated for all 64 zones.
I.e. To program the defaulted zone types for the first four zones use the following:
[INSTALLER CODE] [*]
[1] [*] reference zones 1 - 8
[1] [*] [1] [*] [*] zone 1, zone type 1
[2] [*] [2] [*] [*] zone 2, zone type 2
[3] [*] [4] [*] [*] zone 3, zone type 4
[4] [*] [4] [*] [*] zone 4, zone type 4
How to program using the [*] key to advance:
A third method to program zones using the star advance method is to enter the location number
corresponding to a group of 8 zones you wish to program. Each press of the [*] key will step through
a zone.
I.e. To change zone 12 to an Instant zone, use the following:
[INSTALLER CODE] [*]
[2] [*] reference zones 9 – 16
[*] move to zone 10
[*] move to zone 11
[*] move to zone 12
[4] [*] zone type 4
Table 6 represent the default zone types for the 64 zones represented in 2 different programming methods.
Table 6: Zone Types in String Format
Zones
Loc
Sub-loc
As Strings
Zone Type
1 - 8
1
n/a
0102040404040404
ref above table
9 - 16
2
n/a
0000000000000000
All Disabled
17 - 24
3
n/a
0000000000000000
All Disabled
25 - 32
4
n/a
0000000000000000
All Disabled
33 - 40
5
n/a
0000000000000000
All Disabled
41 - 48
6
n/a
0000000000000000
All Disabled
49 - 56
7
n/a
0000000000000000
All Disabled
57 - 64
8
n/a
0000000000000000
All Disabled

IDS X Series Specifications

General

Key Type	Tactile
Backlight	Yes
Operating Voltage	12VDC
Weight	150g
Operating Temperature	-10°C to +55°C
