 Sub-location 5 is Bus Peripheral Power/Battery Low
This code is reported when a peripheral, on the bus, experiences a low power supply.
 Sub-location 6 is Bus Peripheral Power/Battery Restored
This code is reported when a peripheral, on the bus, power supply is restored.
 Sub-location 7 is Wireless Detector Battery Low
This code is reported when a wireless detector, experiences a low battery.
 Sub-location 8 is Wireless Detector Battery Restored
This code is reported when a wireless detector’s battery is replaced after a low battery is
reported.
Enter a 2-digit reporting code for each of the 8 sub-locations and program as a 16-digit string,
followed by the [*] key.
NOTE: When programming using the string method, reserved sub-locations will still need data to be inputted
into them to maintain the 16-digits needed to successfully program. Inputting data into a reserved sub-location
will not affect the value of the sub-location. Reserved sub-locations have a value of 00.
[INSTALLER CODE] [*] [3] [0] [3] [*] [SUB-LOCATION] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are enabled
Refer to Using Sub-locations to see how to scroll through sub-location using the [*] key.
NOTE: The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
LOCATION 303 Global Reporting Code 4
This location is used to configure global reporting codes to be used in the event that Neither Contact ID or SIA
formats are used. These codes will be used when any of the other formats in Communications Setup -
Advanced have been selected.
 Sub-location 1 is Wireless Detector Supervision Failed
This code is reported when a wireless detector has not reported to the alarm panel after a certain
amount of time.
 Sub-location 2 is Wireless Detector Supervision Restore
This code is reported when a wireless detector restores communication with the alarm system.
 Sub-location 3 is Wireless Receiver Signal Jammed
This code is reported when a wireless receiver detects a signal on the same frequency that is high
enough to interfere with any signals from detectors.
 Sub-location 4 is Wireless Detector Signal Restored
This code is reported when a wireless receiver detects that the signal affecting detector reporting has
disappeared.
 Sub-location 5 is Wireless Detector RSSI Low
This code is for reporting when the received signal strength indicator is lower than the required
strength
 Sub-location 6 is Wireless Detector RSSI Restored
This code is for reporting when the received signal strength indicator is restored to the required
strength.
 Sub-location 7 is Dedicated Panic
This code is reported when the dedicated panic zone is violated. Option 7 in Table 43 needs to be
enabled.
 Sub-location 8 is Test Report
This code is reported at regular intervals (location 32). Option 8 in Table 43 needs to be enabled
 Sub-location 9 is Download Report Code
This is the code that will be sent after a successful connection has been made to the alarm panel with
the download software.
Enter a 2-digit reporting code for each of the 8 sub-locations and program as a 16-digit string,
followed by the [*] key.

IDS X Series Specifications

General

Key Type	Tactile
Backlight	Yes
Operating Voltage	12VDC
Weight	150g
Operating Temperature	-10°C to +55°C
