PCIE-Q57A PICMG 1.3 CPU Card

Page 5

1.3.1 External Interface Panel Dimensions

External peripheral interface connector panel dimensions are shown in 5Figure 1-4.

Figure 1-4: External Interface Panel Dimensions (mm)
