5.3.5 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 8) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU_FAN2 Mode Setting [Full On Mode]
CPU_FAN1 Mode Setting [Full On Mode]
System Temperature Sensor :34ºC/93ºF
CPU Temperature Sensor :36ºC/96ºF
CPU_FAN2 Speed :N/A
CPU_FAN1 Speed :4115 RPM
VCCP :1.136 V
+1.1V :1.152 V
+3.3V :3.264 V
+5V :5.080 V
+12V :12.032 V
+1.05V :1.040 V
+1.6V(V_SM) :1.616 V
+5V_DUAL :5.080 V
VBAT :3.072 V
Fan configuration mode
setting
Select Screen
↑ ↓ Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
v02.67 ©Copyright 1985-2009, American Megatrends, Inc.
BIOS Menu 8: Hardware Health Configuration
Mode Setting [Full On Mode]
Use the Mode Setting option to configure the second fan.
Full On Mode DEFAULT
Fan is on all the time
Automatic mode
The fan adjusts its speed using these settings:
Temp. Limit of OFF
Temp. Limit of Start
Fan Start PWM
Slope PWM 1
PWM Manual mode
The fan spins at the speed set in:
Fan PWM control
