IEI Technology PCIE-Q57A User Manual

PCIE-Q57A PICMG 1.3 CPU Card
Page 15
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
+12V ATX power supply connector 4-pin Molex power connector CPU12V1
Audio kit connector 10-pin header J_AUDIO1
Battery connector 2-pin wafer BAT1
DDR3 DIMM socket 240-pin socket DIMM1
DDR3 DIMM socket 240-pin socket DIMM2
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (CPU) 4-pin wafer CPU_FAN2
Floppy disk drive connector 34-pin box header FDD1
Front panel connector 14-pin header F_PANEL1
Infrared connector 5-pin header IR1
Keyboard and mouse connector 6-pin wafer KB/MS1
Parallel port connector 26-pin box header LPT1
SATA drive connector (1) 7-pin SATA SATA1
SATA drive connector (2) 7-pin SATA SATA2
SATA drive connector (3) 7-pin SATA SATA3
SATA drive connector (4) 7-pin SATA SATA4
SATA drive connector (5) 7-pin SATA SATA5
SATA drive connector (6) 7-pin SATA SATA6
Serial port connector (RS-232) 10-pin header COM1
