PCIE-Q57A PICMG 1.3 CPU Card
Page 36
4.4.1 Socket LGA1156 CPU Installation
WARNING:
CPUs are expensive and sensitive components. When installing the
CPU please be careful not to damage it in anyway. Make sure the CPU
is installed properly and ensure the correct cooling kit is properly
installed.
DO NOT touch the pins at the bottom of the CPU. When handling the
CPU, only hold it on the sides.
CAUTION:
Intel® Core™ i7-900 processor series uses LGA1366 socket and
support Intel® X58 Chipset. Only Intel® Core™ i7-800 processor
series of the Intel® Core™ i7 processor family can be installed into the
on-board LGA1156 socket of the PCIE-Q57A.
To install the CPU, follow the steps below.
Step 1: Disengage the load lever by pressing the lever down and slightly outward to
clear the retention tab. Fully open the lever. See
Figure 4-1.
