PIN DESCRIPTION PIN DESCRIPTION
1 RED 9 VGAVCC
2 GREEN 10 GROUND
3 BLUE 11 NC
4 NC 12 DDCDAT
5 GROUND 13 HSYNC
6 GROUND 14 VSYNC
7 GROUND 15 DDCCLK
8 GROUND
Table 3-19: VGA Connector Pinouts
NOTE:
The Intel® HD Graphics is NOT integrated in all the Intel® Core™ i7 Desktop
processor family and Intel® Core™ i5-700 series processor. An additional
graphic card must be installed in order to support display output. Otherwise,
the display will show “No display output” when connected to the on-board
VGA port.
The following table lists all Intel® Core™ i5 and i3 family processors that
support Intel® HD Graphics:
 Intel® Core™ i5-650
 Intel® Core™ i5-655
 Intel® Core™ i5-660
 Intel® Core™ i5-661
 Intel® Core™ i5-670
 Intel® Core™ i5-680
 Intel® Core™ i3-530
 Intel® Core™ i3-540
 Intel® Core™ i3-550
 Intel® Core™ i3-560
Reference Intel® Core
 i3 Desktop CPU:
http://ark.intel.com/ProductCollection.aspx?familyID=43129&MarketSegment=DT
Intel® Core
 i5 Desktop CPU:
http://ark.intel.com/ProductCollection.aspx?familyID=42912&MarketSegment=DT
Intel® Core
 i7 Desktop CPU:
http://ark.intel.com/ProductCollection.aspx?familyID=28037&MarketSegment=DT
