100
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Id
Parameter
Parameter Description Range Default
Value
customized
P.8
Stand-by/OFF
conguration
0: Antifreeze, anti-block active
1: Antifreeze o and anti-block active
2: Antifreeze anti-block o
3: Not used
0-3 0
P.9
External probe
reading
correction
If the reading of the external probe is not correct it is possible
to correct it in order to compensate any environmental
factors.
-9..9 °C 0
P.10 Not used - - -
P.11
Conguration
Input 1 (40-41)
Setting a value other than zero is not accepted if the function
is already present in another input (*):
0: OFF
1: zone 1 room thermostat generates central heating request
together with remote control (logic in AND)
2: room thermostat zone 1 generates a heating central
heating request as an alternative to the remote control (Logic
in OR)
3: room thermostat zone 2 generates a heating central
heating request as an alternative to the remote control (Logic
in OR)
4: Safety thermostat (low temperature)
0-4 1
P.12
Conguration
Input 2 (14-15)
See notes P.11 0-4 4
P.13
Conguration
Input 3 (1-2)
Not used - -
P.14
ImgBus Input
Conguration
(44-41)
Setting a value other than zero and one is not accepted if
already present in another input:
0: Not used
1: ImgBus
2: TA zone 1
3: TA zone 2
4: Safety thermostat (low temperature)
0-4 1
P.15
Probe congu-
ration (47-48)
0: OFF/Storage tank probe
1: Not available
2: Not available
0-2
e value is
automatically
selected
depending on
the value set
in parameter
A.0
(*) : when connecting a DIM or zones control unit to terminals 21, 40 and 41, parameterP.11 must be set at 2.
