50
INSTALLERUSERMAINTENANCE TECHNICIANTECHNICAL DATA
Summary table of information for C
10
installations (Only Methane 2E - 2H)
VICTRIX EXTRA 12 PLUS VICTRIX EXTRA 24 PLUS VICTRIX EXTRA 35 PLUS
Qmin Qn max Qmin Qn max Qmin Qn max
Heat input [kW] 2,0 12,2 2,8 28,9 2,8 34,0
CO2% of reference [%] 8,8 8,8 8,8 8,8 8,8 8,8
Maximum boiler outlet pressure [Pa] 25 82 25 94 25 97
Minimum boiler outlet pressure [Pa]
-200
(-400 Pa for
C12)
-200
(-400 Pa for
C12)
-200
(-400 Pa for
C12)
-200
(-400 Pa for
C12)
-200
(-400 Pa for
C12)
-200
(-400 Pa for
C12)
Maximum ue gas ow rate [kg/h] 20 49 57
Flue gas temperature 80°C/60°C [°C] 62 74 79
Maximum ue duct length 80/125 [m] 7,7
Maximum ue duct length 80/80 [m] 10
Available head with maximum duct
length [Pa]
6 36 45
Boiler settings
(as indicated in instruction booklet)
See Par. 1 from point 9 on.
