5 - 6
Transpector MPH Operating Manual
SENSOR ID . . . . . . . . . . . . . . . . . . . A user-definable ID for the sensor
DESCRIPTION . . . . . . . . . . . . . . . . A user-definable description for the sensor,
useful for identifying different sensors
SERIAL NUMBER . . . . . . . . . . . . . . The factory serial number of the connected
Transpector MPH, each Transpector MPH
has a unique serial number
IP ADDRESS . . . . . . . . . . . . . . . . . . The IP address of the connected
Transpector MPH
SUBNET MASK . . . . . . . . . . . . . . . . The subnet of the connected
Transpector MPH
GATEWAY . . . . . . . . . . . . . . . . . . . . The gateway of the connected
Transpector MPH
DHCP ENABLED. . . . . . . . . . . . . . . Describes whether DHCP is turned
ON or OFF
MAC ADDRESS . . . . . . . . . . . . . . . The MAC address of the connected
Transpector MPH
PORT NUMBER . . . . . . . . . . . . . . . The Port that the connected
Transpector MPH is using
MASS RANGE . . . . . . . . . . . . . . . . . The mass range of the connected
Transpector MPH (100, 200 or 300 AMU)
DETECTOR TYPE . . . . . . . . . . . . . . The detector type of the connected
Transpector MPH (either FC or CDEM)
EMISSION STATUS . . . . . . . . . . . . The status of the emission of the
Transpector MPH sensor (either ON of OFF)
EM STATUS . . . . . . . . . . . . . . . . . . The status of the Electron Multiplier (if
equipped) of the Transpector MPH sensor
(either ON or OFF)
FILAMENT NUMBER . . . . . . . . . . . The Filament currently in use by the
Transpector MPH sensor (either 1 or 2)
RELEASE . . . . . . . . . . . . . . . . . . . . The firmware version number
WEB UI RELEASE . . . . . . . . . . . . . Transpector Web UI version number
The STATUS window allows for changing IP address, Port Number,
Sensor ID and Description. For more information, see section 5.5.2.4, Changing
the Transpector MPH IP Address and Port Number, on page 5-23 and section
5.5.2.5, Changing the Sensor ID and Description, on page 5-26.
