6.4 EXTERNAL POWER SUPPLY
• Only an Ingenico approved power supply (CE Marked) specified for use
with this terminal must be used.
• Operate only from a power source as specified on the Power Supply
Unit.
6.5 CONNECTIONS
Take due care when attaching cables. Under no circumstances must the PSTN
(i.e. telephone) cable be inserted into the RS232 ports.
Figure 7 - Cable Port Locations
Power Supply
cord
PSTN/Telephone
Cable
ECR Interface/SkyPay-300
Cable
