INGENICO 5100 PAYMARK VERSION 6.0 OPERATING GUIDE Version 1.3
6.6 LIFT LATCH TO OPEN PRINTER LID
To open the printer lid, press the printer latch backwards which will release the
locks and then lift up the printer lid.
Figure 8 - Printer Lid Opening
6.7 PAPER SIZE
The paper roll size is 57mm width and 50mm diameter. Please take note of the
direction of the paper roll.
Figure 9 - Paper Roll Loading
6.8 OPERATING ENVIRONMENT
The operating temperature range for this device is between 5
o
C and 40
o
C.
