Figure 44. Programming File Generator Input Files
8. On the Configuration Device tab, click Add Device. You can select your flash device from the from the Configuration
Device list, or define a custom device using the available menu options. For more information about defining a custom
configuration device, refer to the Configuration Device Tab Settings (Programming File Generator) in the Intel Quartus
Prime Pro Edition User Guide: Programmer
