Note: If unused space is not available, you can use an application image space other than application image 1. In this
case after the update operation completes you must restore the application image by writing the associated
application image (.rpd) to the application slot.
Figure 64. Specifying Parameters for Single .rpd Stored in Flash Memory
Specify Configuration Mode
Select Raw Programming Data
Specify Output Directory
Specify Output File Name
Specify Device Family
Specify Start Address in Flash
Edit
7.
By default, the .rpd file type is little-endian. If you are using a third-party programmer that does not support the little-
endian format, set Bit swap to On to generate the .rpd file in big endian format.
8.
On the Input Files tab, click Add Bitstream. Change the Files of type to SRAM Object File (*.sof). Then, select
factory image .sof file and click Open.
4. Remote System Update (RSU)
UG-20205 | 2019.10.09
Intel
®
Agilex
™
Configuration User Guide
Send Feedback
156
