The following example output shows the generated .map file. The .map lists the start addresses of the factory image, CPB0,
CPB1, and one application image. The remote system update requires these addresses.
BLOCK START ADDRESS END ADDRESS
BOOT_INFO 0x00000000 0x0010FFFF
FACTORY_IMAGE 0x00110000 0x002D3FFF
SPT0 0x002D4000 0x002DBFFF
SPT1 0x002DC000 0x002E3FFF
CPB0 0x002E4000 0x002EBFFF
CPB1 0x002EC000 0x002F3FFF
Application Image 0x002F4000 0x004B7FFF
Configuration device: AFGA014R24A2
Configuration mode: Active Serial x4
Quad-Serial configuration device dummy clock cycle: 15
Notes:
- Data checksum for this conversion is 0xBFFB90A5
- All the addresses in this file are byte addresses
After generating the programming file, you can program the flash memory.
4. Remote System Update (RSU)
UG-20205 | 2019.10.09
Intel
®
Agilex
™
Configuration User Guide
Send Feedback
166
