Intel Agilex User Manual

Table 45. Configuration Firmware Point Block Contents
CPB Start Address + 0x20
Content Value
CPB0 + 0x20 = 0x002E4020
Current application image pointer entry (highest
priority)
0x002F4000
CPB0 + 0x28 = 0x002E4028
Next image pointer entry
0xFFFFFFFF
CPB1 + 0x20 = 0x002EC020
Current application image pointer entry (highest
priority)
0x002F4000
CPB1 + 0x28 = 0x002EC028
Next image pointer entry
0xFFFFFFFF
You can use the QSPI_read function verify that the new image pointer entry value is 0xFFFFFFFF . The QSPI_read function
takes in two arguments:
1. Start address
2. Number of words to read
4. Remote System Update (RSU)
UG-20205 | 2019.10.09
Intel
®
Agilex
™
Configuration User Guide
Send Feedback
174
