Chapter 8 — Intermec Shell Startup Program
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 95
Selecting Other Facilities
As an alternative to selecting an application, you can step through
a number of other useful facilities:
Setup
Set up the printer using its built-in keyboard, see “Setup Mode”
on page 77.
Print Setup
Produce a printout of the printer’s current setup values (test label
“Setup Info”).
Testfeed
Feed out a number of label, ticket, tag, or portions of continuous
stock while the printer auto-adjusts its media feed and
label stop/black mark sensor. It is recommended to perform a
Testfeed each time you load a roll of labels from a new batch or a
different brand.
Test Label
Print a series of four test labels (test labels “Diamonds”, “Chess”,
“Bar Codes #1”, and “Bar Codes #2”) in order to test the
printout quality and printhead alignment. The labels are
presented in an infinite loop, so you can print the series over and
over again. Press Enter for each new label.
Default Setup
Reset all setup parameters to their default values, as listed in
“Default Setup” on page 61.
Software Update
Using the Zmodem communication tool, files can be
downloaded from a PC, either to be stored on a standard
CompactFlash memory card or to upgrade the printer’s firmware.
The following options are available:
• Update CompactFlash card allows the printer to be used as a
CompactFlash card programming device. Any files can be
Note: When an application program is started, it may
automatically change the communication setup. If another
application is selected later, this communication setup will remain
valid, unless the new application includes instructions that
automatically change the setup. The setup could also be changed
manually in the Setup Mode.

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
