Chapter 2 — Installation
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 7
Front View
At the front of the printer are the display window, the indicator
lamps, and the keyboard. These features allow the operator to
control and set up the printer manually.
The front door is held by a snap-lock. Open the front door to
view the various parts on the printer’s front.
Refer to “Options” on page 101, for information on possible
optional devices fitted on the printer’s front.
Front View
Side door
Indicator lamps
Display window
Keyboard
Front door
Print mechanism
Connector
for optional
cutter
