Chapter 3 — Starting Up
20 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
Switching On the Printer
Before switching on the printer, make the necessary connections,
and check that the printhead is engaged.
Switch on the power using the On/Off switch on the rear plate.
The “Power” LED on the front panel lights up when the power is
on. Wait for a few moments while the printer loads the program
and runs some self-diagnostic tests. The Display Window will
show the following progress indicator.
After a short time, the printer is initialized. The progress of the
initialization is indicated by an increasing number of colons on
the lower line in the display.
The type of startup file running in the printer is indicated by the
message shown in the display window immediately after
initialization.
A. Intermec Shell Startup Program
Refer to “Intermec Shell Startup Program” on page 91 for more
information on Intermec Shell. The digits in the lower right
corner of the display indicate the version of Intermec Shell.
Starting

Initializing
:::
ENTER=SHELL
5 sec. v.8.1
4 sec. v.8.1
3 sec. v.8.1
2 sec. v.8.1
1 sec. v.8.1

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
