Chapter 2 — Installation
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 9
Media Compartment
The media compartment is covered by the side door which can
be opened 180° downwards to provide complete access to the
media and ribbon loading area. The door is held closed by a
magnetic lock. It can be completely removed by opening it and
then pulling it forward.
The media can be supplied from a rotating hub or from an
external supply of fanfolded media behind the printer. For more
information, see “Options” on page 101.
Media Compartment
Media supply
roll hub
Side door
Ribbon rewind hub
Slack absorber
Ribbon supply hub
