Intermec EasyCoder PX4i User Manual

Appendix C — Interfaces
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 157
For more demanding applications or for reading bar codes other
than Code 128, choose a regular bar code scanner from
Intermec’s wide product range and connect it to a serial port.
Bar Code Wand Interface
Optional Interfaces
The printer can optionally be fitted with one or two of the
following interface boards at the right-hand side of the printer’s
rear plate:
• Double Serial Interface Board
• Serial/Industrial Interface Board
• IEEE 1284 Parallel Interface Board (only one at a time)
Regardless of any of the interface boards mentioned above are
installed, the printer can also be fitted with one of the following
EasyLAN interface boards for connection to a Local Area
Network (LAN).
• EasyLAN Ethernet Interface
• EasyLAN Wireless Interface
Bar code wand
interface ("wand:")

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
