Intermec EasyCoder PX4i User Manual

Chapter 12 — Adjustments
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 131
Printhead Pressure
The pressure of the thermal printhead against the ribbon or
direct thermal media is factory adjusted. However, the use of
thicker or thinner media than normal could require the printhead
pressure to be readjusted.
Turn the adjustment knob clockwise for increased pressure, or
counterclockwise for less pressure. Print a few labels, preferably
test labels, and check the printout. For help printing test labels,
see “Setting Up the Printer” on page 59. Increased pressure
generally gives a darker printout and vice versa. Repeat until the
desired result is obtained.
To find the basic setting, turn the knob counterclockwise until
there is no pressure left. Test with a piece of media under the
printhead. You should be able to pull it out without more than
just a little resistance. Then turn the knob four full turns
clockwise. Fine-adjust using the trial-and-error method.
Printhead pressure adjustment
Do not use a higher printhead pressure than necessary.
Unnecessary pressure may increase the wear of the printhead
and shorten its life.
Knob

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
