Intermec EasyCoder PX4i User Manual

Chapter 11 — Maintaining the Printer
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 121
Never use any sharp tools for removing stuck labels. The
printhead and rollers are delicate.
Cleaning the Label Stop Sensor
The label stop sensor, which controls the media feed, is partially
enclosed by two plastic guides. Light passes through slots
between the upper and lower part of the sensor. If the guides are
not clean, stuck labels or other objects may block the light beam.
If the printer starts to feed out labels in an unexpected way,
remove the guides as described below and check for anything
blocking the beam of light. If necessary, clean the guides using a
cleaning card or a soft cloth soaked with isopropyl alcohol. Do
not use any other type of chemicals.
Easy
Cod
e
r
PX4
i
Isopropyl alcohol [(CH-3)2CHOH; CAS 67-63-0] is a highly
flammable, moderately toxic, and mildly irritating substance.

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
