Intermec EasyCoder PX4i User Manual

Appendix C — Interfaces
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 155
RS-232 Interface
Interface Cable
Computer end: Depends on computer model
Printer end: DB-9 plug
USB Interface
This printer supports USB v1.1 (also called USB 2.0 full speed).
To use the USB interface for printing from a PC, you need a
special Intermec USB printer driver installed in your PC.
The printer is a so-called “self-powered device.” We recommend
that you only connect one printer to each USB port on the host,
either directly or via a hub. Other devices, like a keyboard and a
mouse, can be connected to the same hub. If you need to connect
more than one Intermec USB printer to a host, you should use
different USB ports.
Using a USB Class A/B cable, connect the Class A plug to your
PC or hub and the Class B plug to your printer.
The USB interface is essentially a one-way communication
interface. There is no communication setup for the USB port.
USB Class A connector
RS-232
("uart1:")

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
