Intermec EasyCoder PX4i User Manual

Chapter 11 — Maintaining the Printer
128 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
Media Jams
Should a media jam occur in the print mechanism, proceed this
way to clear it.
To clear a media jam
1 Always switch off the power before starting to clear the
jammed media.
2 Raise the printhead and pull out the media.
3 If the media has been wound up on or has stuck to the platen
roller, carefully remove it by hand without using any sharp
tools that can damage the delicate platen roller or printhead.
Avoid rotating the platen roller.
4 Cut off any damaged or wrinkled part.
5 If there is any adhesive somewhere in the print mechanism,
remove it using a cleaning card or a cotton swab soaked in
isopropyl alcohol.
6 Reload the media as described in “Loading Media” on
page 23.
7 Switch on the power.
8 Readjust the media feed by raising and closing the printhead
and then pressing Feed.
If you must pull away the media by force causing the platen
roller to rotate, it is very important that the power has been
off for a minute or more. If not, the electronics can be
damaged beyond repair.
Isopropyl alcohol [(CH-3)2CHOH; CAS 67-63-0] is a
highly flammable, moderately toxic, and mildly irritating
substance.

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
