Intermec EasyCoder PX4i User Manual

Chapter 6 — Setting Up the Printer
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 61
Default Setup
The printer’s default setup is listed below, with no options
included.
Ser-Com “uart1:”
Baud rate 9600 bps
Character length 8 bits
Parity None
Stop bits 1 bit
RTS/CTS Disable
ENQ/ACK Disable
XON/XOFF, data to host Disable
XON/XOFF, data from host Disable
New line CR/LF
Receive buffer 1024 bytes
Transmit buffer 1024 bytes
Feed Adjust
Start adjust 0 dots
Stop adjust 0 dots
Media
X-Start 24 dots
Width 424 dots
Label length 1200 dots
Media type Label (with Gaps)
Paper type Thermal transfer
Ribbon Constant 90
Ribbon factor 25
Label offset 0
Ribbon sensor (low diameter) 0 mm
Contrast 0%

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
