Intermec EasyCoder PX4i User Manual

Chapter 6 — Setting Up the Printer
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 69
Print Window 11.81 dots/mm (300 dpi) printhead
Media Type
The Media Type parameters control how the label stop sensor
(LSS) and the media feed work. There are five media type
options:
• Gap is used for adhesive labels mounted on liner (backing
paper) or continuous paper stock with detection slots.
Default.
• Mark is used for labels, tickets, or strip provided with black
marks at the back.
• Continuous is used for continuous stock without any
detection slots or black marks.
• Label (with gaps) is used for adhesive labels mounted on liner.
• Ticket (with mark) is used for labels, tickets, or continuous
stock provided with black marks at the back.
FEED
DIRECTION
Dot #0
Dot-line
on printhead
X-start Width (1-1322)
Origin
Length
Dot #1321
8 mm (0.32 in)
PRINT
PRINT
WINDOW
WINDOW
PRINT
WINDOW
max. 112 mm (4.4 in)
25-120 mm (1-4.7 in)

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
