Intermec EasyCoder PX4i User Manual

Chapter 6 — Setting Up the Printer
68 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
(LSS) has not detected a gap or mark within 150% of the set
length, the media feed is automatically stopped to avoid
feeding out a whole roll of media, because of an LSS
malfunction.
By setting up the X-Start, the Width, and the Length, you will
create a print window inside which the printing can be
performed. Any object or field extending outside the print
window in any direction will either be clipped or cause an error
condition (Error 1003 “Field out of label”), see Intermec
Fingerprint v8.xx, Command Reference Manual.
Print Window 8 dots/mm (203.2 dpi) printhead
FEED
DIRECTION
Dot #0
Dot-line
on printhead
X-start Width (1-896)
Origin
Length
Dot #895
8 mm (0.32 in)
PRINT
PRINT
WINDOW
WINDOW
PRINT
WINDOW
max. 112 mm (4.4 in)
25-120 mm (1-4.7 in)

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
