Questions and Answers:

J
Jessica ParkerJul 31, 2025
What to do if a media jam occurs in my Intermec Barcode Reader?
- K
  Krista MitchellJul 31, 2025
  If a media jam occurs in your Intermec Barcode Reader, follow these steps: 1. Always switch off the power before starting to clear the jammed media. 2. Raise the printhead and pull out the media. 3. If the media has wound up or stuck on the platen roller, carefully remove it by hand, avoiding sharp tools that can damage the platen roller or printhead. Avoid rotating the platen roller. 4. If you must pull away the media by force causing the platen roller to rotate, ensure the power has been off for at least a minute. 5. Cut off any damaged or wrinkled parts. 6. Check for adhesive in the print mechanism; clean with a cleaning card or cotton swab soaked in isopropyl alcohol. 7. Switch on the power. 8. Readjust the media feed by pressing the key.
W
Willie AndersonAug 5, 2025
Why is my Intermec Barcode Reader producing an overall weak printout?
- M
  Michael BakerAug 5, 2025
  An overall weak printout from your Intermec Barcode Reader can be caused by several factors: * **Wrong Paper Type:** Change the parameter to match the paper type. * **Wrong Printhead Voltage:** It may be necessary to replace the CPU board, consider calling service. * **Uneven Printhead Pressure:** Adjust the arm alignment. * **Foreign Particles on Media:** Clean or replace the media. * **Quality of Media or Ribbon:** Match the media ribbon quality. * **Worn Platen Roller:** Check and potentially replace the platen roller; consider calling service.
S
Shannon WalkerAug 11, 2025
Why is my Intermec Barcode Reader printing too dark?
- J
  John ClarkAug 11, 2025
  An overall dark printout from your Intermec Barcode Reader can result from: * **Wrong Paper Type:** Change the parameter. * **Wrong Printhead Voltage:** Replacing the CPU board might be needed; consider calling service. * **Faulty Energy Control:** Replacing the CPU board might be needed; consider calling service.
L
Laura MarquezAug 17, 2025
How to fix missing dot lines on Intermec Barcode Reader printouts?
- H
  hughesjefferyAug 18, 2025
  A large part of a missing dot line on Intermec Barcode Reader printouts can be due to: * **Wrong X-start or Width Parameter:** Change the parameter. * **Failing Strobe Signal:** Check the CPU-board; consider calling service. * **Bad Energy Control Adjustment:** Adjust the energy control; consider calling service.

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %
