Appendix A — Technical Data
138 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
Printing
Print Technique Direct Thermal and Thermal Transfer
Printhead Resolution 8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Print Speed (variable) 100 to 300 mm/sec (± 4 to 12 in/sec)
Print Width (max) 112 mm (4.41 in) - Direct Transfer
110 mm (4.33 in) - Thermal Transfer
Print Length (max) 32767 dots
= 409.5 cm (161.25 in) at 203.2 dpi
=277.5 cm (109.23 in) at 300 dpi
See Note 1
Media Width
(min/max)
25 to 120 mm (1 to 4.72 in.)
Media Roll Diameter
(max)
213 mm (8.38 in) Tear-Off
205 mm (8.07 in Peel-Off
Media Roll Core
Diameter
38 to 40 mm (1.5 in)
76 mm (3 in) with adapter fitted
Ribbon Width
(min/max)
55 to 110 mm (2.17 to 4.33 in)
Ribbon Roll Diameter
(outer), max.
80 mm (3.15 in)
± 450 m (1476 ft) of ribbon
Print Technique Direct Thermal and Thermal Transfer
Ribbon Roll Core
Diameter (inner)
25 mm (1 in)
Print Directions 4
Note 1: The maximum print length is also restricted by the amount of
free SDRAM memory.
Modes of Operation
Tear-Off (Straight-through) Yes
Cut-Off Option With cutter
Peel-Off (Self-strip) Option With rewinder
Internal Batch Takeup Option With rewinder
