Intermec EasyCoder PX4i User Manual

Chapter 6 — Setting Up the Printer
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 75
Print Speed
The print speed is variable between 100 and 300 mm/sec.
Generally, the lower the speed, the better the printout quality.
This is especially true when printing bar codes with the bars
running across the media path (“ladder style”), when printing on
demanding face materials, and when printing at low ambient
temperatures. The default setting is 200 mm/sec (approximately
8 in/sec).
Refer to “Intermec Supplies” on page 161 for recommended
maximum print speed for various combinations of Intermec
media and transfer ribbon.
LSS Test
The function on the label stop sensor (LSS) can be tested
automatically or manually as described in “Adjustments” on
page 129.
LTS (Label Taken Sensor)
The sensitivity of the LTS can be tested and adjusted as described
in “Adjustments” on page 129.
Returning to Factory Default Setup
There are two ways to return to the factory default setup of the
printer:
• Insert a special CompactFlash memory card and restart the
printer.
• Use the printer’s built-in keyboard.
To return to factory default setup using the keyboard
1 Lift the printhead.
2 Switch on the power to the printer and press F5/i and wait
until the printer beeps.
Quickly press the following keys:
d/F4, c/F2, c/F2, e/F1
3 The following message will be displayed:
Factory Default?
Enter=Yes ESC=No

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
