Intermec EasyCoder PX4i User Manual

Chapter 6 — Setting Up the Printer
76 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
4 Within 10 seconds, press Enter to reset the printer to factory
default. The parameters will be reset and the printer will
continue the normal startup.
If you press c/F2 or wait until the 10 seconds time-out has
passed, the normal startup process will continue without any
reset being performed.
Note: If any of the files "card:NOSHELL.CFG",
rom:NOSHELL.CFG", or "c:NOSHELL.CFG"exists in the
printer’s memory, no reset to factory default will be performed.
The factory default will remove all files used to store settings. It
will not reset settings that already has been read when the files are
removed. This means that EasyLAN Wireless settings (SSID,
keys, etc.) will retain their values from the previous start.
However, the next reboot will reset them to factory default.

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
