Chapter 6 — Setting Up the Printer
66 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
•A positive stop adjustment means that the normal media feed
after the printing is completed will be increased by the
specified value.
•A negative stop adjustment means that the normal media
feed after the printing is completed will be decreased by the
specified value.
Recommended Feed Adjustments
The following settings allow printing from the top of the label.
Minor deviations from the recommended values may be required
due to various combinations of media types, roll size, type of
media supply device, and individual differences between printers.
Media
The media parameters tell the firmware the characteristics of the
media that will be used, so the printout will be positioned
correctly and get the best quality possible.
Media Size
The size of the printable area is defined by three parameters;
X-Start, Width, and Length.
Adjustment
type
8 dots/mm
203.2 dpi
11.81 dots/mm
300 dpi
Distance
Tear-Off (Straight-through)
Start adjust -108 dots -160 dots 13.5 mm/ 0.54 in
Stop adjust 0 dots 0 dots 0
Peel-Off (Self-strip)
Start adjust -80 dots -118 dots 10 mm/0.39 in
Stop adjust -40 dots -60 dots 5 mm/0.20 in
Cut between labels with gaps
Start adjust -287 dots -424 dots 35.9 mm/1.41 in
Stop adjust +176 dots +260 dots 22 mm/0.87 in
Cut fix and variable length strip
Start adjust -294 dots -434 dots 36.8 mm/1.45 in
Stop adjust +298 dots +440 dots 37.3 mm/1.47 in
