Chapter 2 — Installation
8 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
Rear View
The rear plate contains the On/Off switch, the AC power cord
socket, and various interface connectors and slots.
Rear View
On/Off Switch
AC Power cord socket
Memory card slot
Machine label
RS-232 serial interface
("uart1:")
Provision for two optional
interface boards
Bar code wand socket
("wand:")
USB Interface ("usb1:")
Provision for EasyLAN
Wireless antenna
(option)
Provision for EasyLAN
Ethernet connection
(option)
Intake slot for external
media supply
Intake slot for external
media supply

Table of Contents

Other manuals for Intermec EasyCoder PX4i

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intermec EasyCoder PX4i and is the answer not in the manual?

Intermec EasyCoder PX4i Specifications

General IconGeneral
Print technologyDirect thermal
Maximum resolution300 x 300 DPI
DisplayLCD
Product colorSilver
Keyboard layoutNumeric
Standard interfacesRS-232, USB 2.0
Internal memory16 MB
Media thickness2.4/10 mm
Maximum label width120 mm
Maximum label length2.7 m
Maximum roll diameter213 mm
Supported network protocolsTCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements90 - 265 VAC, 45 - 65Hz
Power consumption (standby)20 W
Power consumption (printing)125 W
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)40 - 104 °F
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth482 mm
Width238 mm
Height275 mm
Weight12850 g
