Chapter 11 — Maintaining the Printer
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 123
Replacing the Printhead
The printhead is subject to wear both from the direct thermal
media or transfer ribbon and from the rapid heating and cooling
process during printing. Thus, the printhead will require periodic
replacement.
Time between printhead replacements depends on the print
images, the type of direct thermal media or ribbon in use, the
amount of energy to the printhead, the print speed, the ambient
temperature, and several other factors.
To replace the printhead
1 Open the front and side doors.
While replacing the printhead, the power must be off. The
firmware will not detect the new printhead resistance and
density until the printer has been restarted.
Note: Check that the density of the new printhead matches the
printhead you are replacing. While you can switch between
densities at will, the printout will be affected accordingly.
