Intermec EasyCoder PX4i User Manual

Chapter 6 — Setting Up the Printer
74 EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version)
Test Labels
Diamonds Chess
Bar Codes #1 Bar Codes #2
Setup Info Hardware Info
974 ohms/11.81 dots/mm
UART1 9600-8-N-1 RTS/CTS DISABLE ENQ/ACK DISABLE XON/XOFF DATA TO HOST DISABLE DATA FROM HOST DISABLE NEW LINE CR/LF REC BUF 1024 TRANS BUF 1024 PRINT CONFIG NEW LINE CR/LF STARTADJ 0 STOPADJ 0 XSTART 36 WIDTH 1286 LENGTH 5000 MEDIA TYPE LABEL (w GAPS) PAPER TYPE TRANSFER LABEL CONSTANT 100 LABEL FACTOR 40 RIBBON CONSTANT 100 RIBBON FACTOR 25 LABEL OFFSET 0 RIBBON SENSOR 8 RIBBON LOW DIAMETER 0 CONTRAST +0% PAPER SENSOR 8 PAPER LOW DIAMETER 0 TESTFEED 77 162 3 6 HEAD RESIST 974 PRINT SPEED 100 FIRMWARE Fingerprint 8.30 MCS1743 DD-MMM-YY hh:mm:ss Boot DD-MMM-YY hh:mm:ss Hardware 1-971652-50 / PSU / 1.1 / 0052-000000 1-971653-25 / Console / 1.0 / 0053-000000 1-959035-00 / TPH / 0.0 / 00037-00001 1-971630-50 / CPU / 1.1 / 0030-001033 Model PX4i Hardware version 4.0 (CLIC version 1) Ram 8192 (k) Flash 0+4096 (k) CompactFlash 0 (k) c: 4077568 bytes free tmp: 1769700 bytes free Odometer 0 (m)

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
