Chapter 12 — Adjustments
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 133
In the Print Defines part of the Setup Mode, you have two ways
to test the label stop sensor if you have a detection problem; LSS
Auto and LSS Manual.
The menu provides only indications from the label stop sensor
unit. The testing menu can determine if the sensor unit is not
physically in position, is blocked by dust or stuck labels, or is
defective in some way. Furthermore, this is an aid if media has
detection complications.
LSS Auto is the quick and normal way to determine if the label
stop sensor works properly and is able to detect gaps, slots, or
black marks.
LSS Manual shows the actual setting provided by the latest
TESTFEED operation. It is also possible to try other settings.
LSS Manual is primarily intended for service and is not described
in this manual.
LSS Auto
Check that the printer is set up for the type of media loaded
in your printer (Setup Mode/Media/Media type/LABELS
(with GAPS);TICKET (with MARK), TICKET (with
GAPS), FIX LENGTH STRIP; or VAR LENGTH STRIP.
Perform a TESTFEED by simultaneously pressing Shift and
Feed on the printer’s keyboard.
Make sure that there is a label—not a gap or mark—at the
LSS.
Check that the media is routed as close to the center section as
the guides allow.
Enter the Setup Mode (see “Setup Mode” on page 77) and go
to Setup Mode/Print Defines/LSS Test/LSS Auto.
The menu should look like this with the cursor placed in the
center:
Note: There is no way to adjust the LSS-function. The menus
only indicate values from the LSS obtained by performing a
TESTFEED operation.
