Intermec EasyCoder PX4i User Manual

Appendix A — Technical Data
EasyCoder PX4i Bar Code Label Printer User’s Guide (Fingerprint Version) 141
Accessories and Options
Integral Self-strip Unit with
Liner Takeup
Option 1, 2 For peel-off and
batch takeup
Media Roll Retainer Option 3
Fanfold Guide Option 3
Cutter Option 3
Label Taken Sensor Option 1, 2
Real Time Clock Option 1, 2 10+ years life
Parallel Interface Board Option 1, 2 IEEE 1284
Double Serial Interface Board Option 1, 2 2 serial ports
Serial/Industrial Interface Board Option 1, 2
EasyLAN Ethernet Interface Option 1, 2
EasyLAN Wireless Interface Option 1, 2
Built-in Alphanumeric Keyboard Option 1, 2
External Alphanumeric
Keyboard
Option 3
CompactFlash Protection Plate Option 3
CompactFlash Cards for various
purposes
Option 3 8 MB-1 GB
Option 1: Factory installed option.
Option 2: Field-installable kit. Installation should be performed by a
service technician.
Option 3: Operator-installable option.

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
